| Thumbnail | SKU | Type 1 | Type 2 (mm²) | Quantity | ||
|---|---|---|---|---|---|---|
|
1100 1324 | Connection strip Nylbloc - Black | 2.5 |
|
||
|
|
1100 1325 | Connection strip Nylbloc - Black | 6 |
|
||
|
|
1100 1326 | Connection strip Nylbloc - Black | 10 |
|
||
|
|
1100 1327 | Connection strip Nylbloc - Black | 16 |
|
||
|
|
1100 1328 | Connection strip Nylbloc - Black | 25 |
|
||
|
|
1100 1329 | Connection strip Nylbloc - White | 2.5 |
|
||
|
|
1100 1330 | Connection strip Nylbloc - White | 6 |
|
||
|
|
1100 1331 | Connection strip Nylbloc - White | 10 |
|
||
|
|
1100 1332 | Connection strip Nylbloc - White | 25 |
|
Connection strip Nylbloc – capacity 2.5 mm² – max. current 24 A
•Nylbloc™ – connection strips and connectors without screws
• 12 elements with captive screws
• Supplied with screws undone
•Flame retardant polypropylene (– 25 °C to + 100 °C)
•Ambient temperature from – 25 °C to + 55 °C (T 55)
•Conform to EN 60998-2-1 and EN 60664-1
•Rated capacity: : 2.5 mm²
•Hole Ø : : 2.5 mm
•Max current : : 24 A
| Connection strip Nylbloc – Black | |
| Type | REF. |
| 2.5 mm2 | 0 342 11 |
| 6 mm2 | 0 342 13 |
| 10 mm2 | 0 342 15 |
| 16 mm2 | 0 342 17 |
| 25 mm2 | 0 342 19 |
| Connection strip Nylbloc – White | |
| Type | REF. |
| 2.5 mm2 | 0 342 21 |
| 6 mm2 | 0 342 23 |
| 10 mm2 | 0 342 25 |
| 16 mm2 | 0 342 27 |
| Brand | |
|---|---|
| Type 1 | Connection strip Nylbloc – Black, Connection strip Nylbloc – White |
| Type 2 (mm²) | 2.5, 6, 10, 16, 25 |
