| Thumbnail | SKU | Cross Section area (mm) | Conductor Ø (N x mm) | Thickness (mm) | Overall Ø (mm) | Quantity |
|---|
Specification : SNI 04-6629.3
60227 IEC 02
Application : Single core insulated conductor, without sheath for general purpose .Suitable for fixed protected installation or on, lighting or controller gear for rated voltage up to 450/750 V.
Colour : Black,Blue,Red,Yellow,Grey,Green
| Dimension and Weight | ||||
| Cross Section area | Conductor Ø | Thickness | Overall Ø | Cable Weight(100m) |
| mm2 | N X mm | mm | mm | Kg |
| 1.5 | 30 x 0.25 | 0.78 | 3.15 | 2.20 |
| 2.5 | 50 x 0.25 | 0.85 | 3.75 | 3.35 |
| 4 | 57 x 0.30 | 0.90 | 4.43 | 5.15 |
| 6 | 85 x 0.30 | 1.15 | 5.50 | 7.80 |
| 10 | 80 x 0.40 | 1.20 | 6.53 | 12.0 |
| 16 | 7 x 18/0.40 | 1.20 | 8.28 | 18.85 |
| 25 | 7 x 28/0.40 | 1.28 | 9.90 | 28.50 |
| 35 | 7 x 40/0.40 | 1.32 | 11.40 | 39.50 |
| 50 | 7 x 57/0.40 | 1.47 | 13.40 | 55.30 |
| 70 | 7 x 80/0.40 | 1.62 | 16.04 | 75.50 |
| Berat | N/A |
|---|---|
| Brand | |
| Cross Section area (mm) | 1,5, 2,5, 4, 6, 10, 16, 25, 35, 50, 70 |
| Conductor Ø (N x mm) | 30 x 0.25, 50 x 0.25, 57 x 0.30, 85 x 0.30, 80 x 0.40, 7 x 18/0.40, 7 x 28/0.40, 7 x 40/0.40, 7 x 57/0.40, 7 x 80/0.40 |
| Thickness (mm) | 0.78, 0.85, 0.90, 1.15, 1.20, 1.28, 1.32, 1.47, 1.62 |
| Overall Ø (mm) | 3.15, 3.75, 4.43, 5.50, 6.53, 8.28, 9.90, 11.40, 13.40, 16.04 |
