| Thumbnail | SKU | Type | Size | Quantity | Description | ||
|---|---|---|---|---|---|---|---|
|
|
1100 1467 | RSES - 5213 (Elbow Pin Type) | 3 x 1 x 35 |
|
RSES – 5213 (Elbow Pin Type | ||
|
|
1100 1468 | RSSS - 5213 (Straight Pin Type) | 3 x 1 x 35 |
|
RSSS – 5213 (Straight Pin Type) |
| Raychem separable Screened Adaptors are designed to connect single-core polymeric cables to |
| medium voltage equipment (transformers, switchgears, motors etc.) up to 24 kV. |
| Made of crosslinked EPDM and protected with a minimum 3 mm moulded conductive shield connected to earth, Raychem deadbreak adaptors are suitable for both indoor and outdoor installations. |
| Their wide application range allows a minimum number of bodies to cover several different cable cross-sections without the need for additional cable adaptors. The cut-back dimensions for all cable sizes are the same for our Raychem RSSS and Raychem RSES |
| adaptors. |
| Raychem Screened Adaptors are equipped with a capacitive test point to ensure that the circuit is not energised before disconnection. The capacitive test point is protected by a conductive cap. A range of high strength bimetallic compression connectors tested to VDE 0220 are offered to connect both aluminium and copper conductor cables. |
| After cable preparation and lubrication, the Raychem Screened Adaptors can simply be slid into place under virtually all conditions. A separable mounting system provides for an easy installa- tion of the adaptor onto the bushing. |
| Brand | |
|---|---|
| Type | RSES – 5213 (Elbow Pin Type), RSSS – 5213 (Straight Pin Type) |
| Size | 3 x 1 x 35 |
